Luocute Mini Linear Rail Guides Slide Actuator, 100mm Effective Stroke Length for CNC Router Parts X Y Z Linear, T6x4 Screw 28 Stepper Motor Rail Guides Slide Actuator

1. [100mm Stroke] Our linear stage actuator could achieve accurate positioning with 100mm effective stroke, 1.8 degree step angle, 6mm diameter, 4mm pitch. 2. [Single Rail Design] With single rail design, the linear rail Guides slide actuator provides stable operation with low noise, suitable for X, Y, Z axes applications. 3. [Metal Structure] The linear motion stage is made from aluminum alloy with a thickened bottom plate for increased stability during operation, ensuring long lasting performance. 4. [High Performance] Our linear stage actuator can handle heavy horizontal and vertical loads, with high positioning accuracy, efficiency, and stability. 5. [Versatile Usage] Ideal for CNC milling equipment, detection equipment, optical laboratory, fine tuning displacement, production machinery and more. Spec: Item Type: Linear Stage Actuator Material: Aluminum Alloy Effective Stroke: Approx. 100mm / 3.94in Screw Rod Specification: T6x4 Screw Rod: T6 Pitch: 4 (The distance the slider moves on the screw rod when the motor rotates one full circle is 4mm) Screw Rod Accuracy: ±0.01mm Load: Horizontal ≤5KG, Vertical ≤1KG Positioning Accuracy: ±0.1mm Holding Torsion: 6N.cm Current: 0.6A Resistance: 5.5Ω Inductance: 3.2MH Speed: 0-120mm/s Step Angle: 1.8 degree How to Use: Direct installation and use. packing list: 1 x Linear Stage Actuator

• [100mm Stroke] Our linear stage actuator could achieve accurate positioning with 100mm effective stroke, 1.8 degree step angle, 6mm diameter, 4mm pitch.
• [Single Rail Design] With single rail design, the linear rail Guides slide actuator provides stable operation with low noise, suitable for X, Y, Z axes applications.
• [Metal Structure] The linear motion stage is made from aluminum alloy with a thickened bottom plate for increased stability during operation, ensuring long lasting performance.
• [High Performance] Our linear stage actuator can handle heavy horizontal and vertical loads, with high positioning accuracy, efficiency, and stability.
• [Versatile Usage] Ideal for CNC milling equipment, detection equipment, optical laboratory, fine tuning displacement, production machinery and more.
